+ Comfort 1.0
Material & composition:
Drive units made of aluminum and anodized for corrosion protection
Bed frame made of powder-coated aluminum
Mechanical components manufactured in Germany
Slatted frame with shoulder comfort zone and slats made of high-quality beech wood
Claddings made of wood-based materials
Annual consumption for one cycle per day: 365 x 160 Watts x travel time 1 min. = 0.97 kWh
Available sizes*:
200 x 180. 200 x 160 90 x 200
Finishes:
*Alpin White W1100 ST9
**Oak Hamilton 3303 ST10
***Stone gray U727 ST9
Accessories:
+ Sofa. + Desk. + Library
Tested and certified by TÜV – Rhineland
Product Description
The product is an electrically height-adjustable bed-desk combination.
The drive units (left – right) each have a gear motor connected to a controller and a tip switch.
By pressing and holding the key switch and then pressing the tip switch on the outside of the column, the bed can be moved continuously between the pre-programmed endpoints.
When lowering, the bed feet extend and the attached desk top moves to the floor. When raising, the desk top is lifted back to its predefined position. The bed feet fold in upon reaching the upper endpoint.
The +Comfort bed is designed for operation at 230V.
The endpoints are set by professional staff using a programming device available only to them.
The endpoints cannot be changed by the user.
Safety
For safety, there is a key switch with an emergency stop function installed, which immediately interrupts the power supply to the controller when the key is released, bringing the lift bed to an immediate stop.
If one unlocks the interruption of power supply to the controller with the key and activates the button for upward or downward movement, the lift bed can again be moved up or down to the referenced endpoint.
Installation Height / Assembly
The +Comfort Bed can be mounted from a room height starting at 2,400 mm.
Installation must be carried out exclusively by our trained professional staff.
